Model 3300-PK Series
BC Purple K Dry Chemical Portable Fire Extinguisher
Red glossy polyester coated steel cylinder with hose squeeze grip control nozzle and wall mounting bracket. Electrically non-conductive siliconized potassium bicarbonate dry chemical. Contents stored under pressure at approximately 195 PSI (13.4 bars).
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | ABC Multi-Purpose Dry Chemical Extinguishers [3002, 3005, 3005-3, 3006, 3010, 3020]; BC Purple K Dry Chemical Extinguishers [3302-PK, 3305-PK, 3310-PK, 3320-PK] | 0 | 1 MB | ||
| | MasterSpec: 104416, Fire Extinguishers (pdf) | 0 | 180 KB | ||
 | | MasterSpec: 104416, Fire Extinguishers (doc) | 0 | 151 KB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB |
Specifications
| Capacity | 2.5 Lbs, 5 Lbs, 10 Lbs, 20 Lbs |
| UL | 30B:C, 10B:C, 80B:C, 120B:C |
| UL Models | All models in this series |
| Height | 15.25", 24", 20.5", 15.5" |
| Diameter | 4.25", 5", 7", 3" |
| Range of Stream | 12 thru 18', 15 thru 21', 9 thru 15' |
| Type of Discharge | Hose |
| Pressure | 195 PSI |
