Model 2851 thru 2853
Braided Synthetic Rubber Hose
This non-collapsible braided synthetic rubber hose is intended for use with continuous flow reels. Construction features permit flow while hose is coiled on reel. Used with Model 2860 series couplings. The hose is a multiple ply synthetic rubber hose with red exterior 600 PSI/41.3 bars burst test pressure 300 PSI/20.6 bars proof test pressure and 150 PSI/10.3 bars recommended working pressure. Model 2851 is a ¾” 2-ply hose. Model 2582 is a 1” 2-ply hose and Model 2853 is a 1.5” 4-ply hose.
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | Continuous Flow Hose Reels and Accessories [Hose Reels 2836, 2837, 2838, 2839, 2840, 2841, 2842; Braided Synthetic Hose 2851, 2852, 2853; Couplings for Hose 2861, 2862, 2863] | 0 | 758 KB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 9 MB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB |
Specifications
| Material | Synthetic Rubber |
| Size | 0.75", 1", 1.5", Two Ply, Four Ply |
| Pressure | 600 PSI Burst Test Pressure, 300 PSI Proof Test Pressure, 150 PSI Recommended Working Pressure |
| Coupling | 2861, 2862, 2863 |
| Thread | Must be specified by customer |
| Length | 50', 75', 100' |
