Model 6040
Roof House
This equipment house is used to provide roof hose stations maintaining readily available fire protection for extensive roof areas. The roof house accommodates 100 feet (30.4 meter) of 1-1/2 inch (3.8 cm) lined hose. It has a 14 ga. electro-galvanized steel base 26 ga. corrugated galvanized steel platform and 18 ga. steel cover powder-coated with an electrostatically-applied thermally-fused red polyester finish. The cover is provided with a spring-loaded latch handle stainless steel continuous hinge and 4 inch (10.2 cm) high "Fire Hose" lettering. Three access sleeves accommodate connections into the building. Minimum Required Equipment to be stored in House (NOT INCLUDED EACH SOLD SEPARATELY)1/2” Double Female Valve [Model 4119]1-1/2” Double Female Valve [Model 4120]1-1/2” Single Jacket Hose [Model 2901]1-1/2” Brass Hose Coupling [Model 2934]1-1/2” Brass Fog Nozzle [Model 2962]1-1/2” Brass Double Male Adapter [Model 2830]
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | Roof Hose & Equipment [6040| 35" Side-to-Side x 41" Front-to-Back x 9" Height] includes list of minimum and optional equipment | 0 | 4 MB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 9 MB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB |
Specifications
| Material | 18 Gauge Galvanized Steel Red Glossy Polyester Coating |
| Height | 9", 23.625" |
| Width | 35", 12.25", 11", 30" |
| Depth | 42" |
| FM | FM Compliant, Contact Potter Roemer for details |
Models
Powder-coated with an electrostatically-applied, thermally-fused, red polyester finish. 14 gauge electro-galvanized steel base, 26 gauge corrugated galvanized steel platform, and 18 gauge steel cover. Cover provided with spring-loaded latch, handle, stainless steel continuous hinge, and 4 inches (10.2 cm) high, "Fire Hose" lettering. Three access sleeves accommodate connections into the building. Roof curbing by others.----------------Minimum Required Equipment to be stored in House(NOT INCLUDED, EACH SOLD SEPARATELY) 1/2" Double Female Valve [ Model 4119] 1-1/2" Double Female Valve [ Model 4120] 1-1/2" Single Jacket Hose [ title="Model 2901">Model 2901] 1-1/2" Brass Hose Coupling [ Model 2934] 1-1/2" Brass Fog Nozzle [ Model 2962] 1-1/2" Brass Double Male Adapter [ Model 2830]
